MODEL |
LGS124P |
|
Standards |
IEEE 802.3, 802.3u, 802.3x, 802.3ab,
802.3az, 802.3af, and 802.3at (PoE+)
|
|
Number of Ports |
24-ports switch with 12 PoE+ ports
(ports 1–6 and 13–18) and dedicated
PoE power budget of 120 W
|
|
MAC Address Table Size |
8,000 entries |
|
Bandwidth |
48 Gbps (non-blocking) |
|
Performance |
Full line rate and forwarding rate of 64B
frame at: 1.488 Mpps for 1000M port,
0.1488 Mpps for 100M port,
0.01488 Mpps for 10M port
|
|
Quality of Service |
802.1p and DSCP |
|
Status LEDs |
Link, speed, activity, and PoE indicators |
|
Power Supply |
Internal |
|
Power |
100–240V AC, 50/60Hz |
|
Power Saving |
Cable connected detection
Sleep mode
|
|
Power Consumption n Idle/Use (100% Traffi c) |
7.79W / 17.65W |
|
Fan |
One |
|
Unit Dimensions |
440 x 200 x 44 mm
(17.3 x 7.9 x 1.7 in.)
|
|
Unit Weight |
2.758 kg (6.08 lbs) |
|
Temperature (Operating) |
0 to 50°C (32 to 122°F) |
|
Temperature (Storing) |
-40 to 70°C (-40 to 158°F) |
|
Humidity |
10 to 90% (non-condensing) |
|
Certifi cations |
FCC Class A, CE, UL, CB |
|
Mounting |
Rack mount |
|
Minimum System
Requirements
|
Connected devices need Ethernet
connectivity and Ethernet cables
|
|
Warranty and Support |
Lifetime limited warranty
Linksys.com/ business/support
|
